The DRV883x device series provides an integrated motor driver solution for cameras, consumer products, toys, and other low-voltage or battery-powered motion control applications. This device is capable of driving a DC motor or other devices (such as solenoids). The output driver module consists of N-channel power MOSFETs configured as an H-bridge to drive the motor windings. An internal charge pump is used to generate the required gate drive voltage.
The DRV883x device series is capable of providing an output current of up to 1.8A. It operates with a motor supply voltage ranging from 0 to 11V, and a device supply voltage within the range of 1.8V to 7V.
The DRV8837 features a PWM (IN/IN) input interface, while the DRV8838 device boasts a PH-EN input interface. Both interfaces are compatible with industry-standard devices.
It also provides internal shutdown functions for overcurrent protection, short circuit protection, under-voltage lockout, and overheat protection.

H-bridge motor driver
Drive a DC motor or other loads
Low MOSFET on-resistance: HS+LS280m0
1.8A maximum drive current
·Independent motor and logic power pins:
Motor VM: 0 to 11V
Logic VCC: 1.8 to 7V
·PWM or PH-EN interface
.DRV8837: PWM, IN1, and IN2
DRV8838: PH and EN
·Low-power sleep mode, with a maximum sleep current of only 120nA
.nSLEEP pin
Small package size
8-pin WSON package with heat dissipation pad
2.0mm x 2.0mm
Protection features
VCC Under Voltage Lockout (UVLO)
Overcurrent protection (OCP)
Thermal shutdown (TSD)
